Seating Plans
        IBC 2003 Compliant
   (ADA seats not shown in drawings)

The drawings below reflect only a few of our suggested seating plans available. We can custom design
and manufacture many system sizes and configurations to fit your seating requirements and site restrictions. Contact us for a free consultation, and we will be glad to help find the best solutions for your needs and budget.

Note: Specs, .dwg CAD drawings, Foundation Plans and Anchoring Requirements available upon request.

3D drawing show with optional powder coated planks for contrast


10 Row Systems



       10 Row x 55' 6" (316 seats, or 288 + 5 HC)


        10 Row x 61.5 (356 seats w/o ADA seating)   NOTE: All systems are available with ADA seating

         10 Row x 91' 6" (529 seats, or 497 + 6 HC)

   10 Row x 133' 6" (740 + 8 HC)

          10 Row x 175' 6" (1035 seats, or 983 + 10 HC)               Printable PDF

15 Row Systems


            15 Row x 61' 6" (531 seats, or 495 + 6 HC)



            15 Row x 121' 6" (1047 seats, or 993 + 10 HC)


               15 Row x 175' 6" (1545 seats, or 1473 + 13 HC)
