Force Series Equipment
  Assembly Instructions


 Materials
A(1) Vertical PostK(4) 5/8" Anchor Bolt
B(1) Main Extension ArmL(12) 5/8" Hex Nut
C(2) Parallel LinkageM(1) Anchor Footing Template
D(1) H-Frame Backboard MountN(4) Anchor Footing Rebar
E(1) Spring-Assist CartridgeO(8) 5/16" x 1" Machine Screw
F(1) Crank Adjustment CylinderP(8) 5/16" Flat Washer
G(2) ½" x 4 ½" Hex BoltQ(8) 5/16" Lockwasher
H(5) ½" x 10" Hex BoltR(8) 5/16" Hex Nut
I(1) ½" x 11" Hex BoltS(1) Rim Height Sticker
J(8) ½" LocknutT(1) Rim Height Indicator
